Sterilization, disinfection, removal of fishy smell, deodorization, and skin surface sterilization.Can be applied to the cleaning of long-term caregivers, hand disinfection of medical care personnel, and cleaning of building floors and environment.
Air Ozone
| Voltage | AC110V~AC230V (DC12V Adapter) |
| OZONE（O3） OZONE(O3) Production Volume | OZ-80AS 80mg / Hr ± 10% OZ-100AS 100mg / Hr ± 10% OZ-120AS 120mg / Hr ± 10% |
| Size | 156(H)*86(L)*84(D)/mm |
| Power Consumption | OZ-80AS 5.5W OZ-100AS 7W OZ-120AS 9W /± 10% |
| Weight | OZ-80AS 500g OZ-100AS 520g OZ-120AS 520g |
| Suitable Space | OZ-80AS 3-15ping OZ-100AS 3-25ping OZ-120AS 6-30ping |
| Temperature Range for Application | -5°C~45°C |
Favored by Hospitals
| Voltage | Personalization |
| Water Discharge | 8 ~ 12 ℓ / min |
| OZONE (O3) Density in Water | 0.8 ppm ~ 1.8 ppm |
| OZONE (O3) Density in Air | Below 0.01 ppm |
| Power Consumption | 45W |
| Size | 350(H)*500(L)*195(D) mm |
| Temperature Range for Application | 5°C ~ 45°C (not exceed 60°C) |
| Weight | 12 kgs |
| Else | 1. Continuous use 4 hours requires 30 minutes break 2. required water pressure above 1 kg/cm² 3. Accessories: Fuhan's special stainless steel flexible pipes |
Commercial Model
| Voltage | Personalization |
| Water Discharge | 12 ~ 25 ℓ / min |
| OZONE (O3) Density in Water | 0.6 ppm~1.2 ppm |
| OZONE (O3) Density in Air | Below 0.01 ppm |
| Power Consumption | 15W |
| Size | 215(H)*180(L)*110(D) mm |
| Temperature Range for Application | 5°C ~ 45°C (not exceed 60°C) |
| Weight | 4.2 kgs |
| Else | required water pressure above 1 kg/cm² |
Attached sensor switch type
| Voltage | Personalization |
| Water Discharge | 8 ~ 12 ℓ / min |
| OZONE (O3) Density in Water | 0.6 ppm ~ 1.2 ppm |
| OZONE (O3) Density in Air | Below 0.01 ppm |
| Size | 265(H)*350(L)*135(D) mm |
| Power Consumption | 18W |
| Temperature Range for Application | 5°C ~ 45°C (not exceed 60°C) |
| Weight | 6.8 kgs |
| Else | 1. required water pressure above 1 kg/cm² 2. Accessories: Fuhan's special stainless steel flexible pipes |
Tabletop models (with sensor switches)
| Voltage | Personalization |
| Water Discharge | 8 ~ 12 ℓ / min |
| OZONE (O3) Density in Water | 0.6 ppm ~ 1.2 ppm |
| OZONE (O3) Density in Air | Below 0.01 ppm |
| Power Consumption | 18W |
| Size | 430(H)*155(L)*155(D) mm |
| Temperature Range for Application | 5°C ~ 45°C (not exceed 60°C) |
| Weight | 7 kgs |
| Else | 1. required water pressure above 1 kg/cm² 2. Accessories: Fuhan's special stainless steel flexible pipes |
Professional Spray Gun Combination Model
| Voltage | Personalization |
| Water Discharge | 12 ~ 14 ℓ / min |
| OZONE (O3) Density in Water | 0.5 ppm ~ 1 ppm |
| OZONE (O3) Density in Air | Below 0.01 ppm |
| Size | Machine: 1300(H)*520(L)*760(D) mm Spray gun: 650(H)*200(L)*40(D) mm |
| Temperature Range for Application | 5°C ~ 45°C (not exceed 60°C) |
| Else | 1. required water pressure above 1.5 kg/cm² 2. Using clean water as backup source of water 3. Length of power line is 10 m |
| Voltage | Personalization |
| Water Discharge | 4 ~ 6 ℓ / min |
| OZONE (O3) Density in Water | 0.6 ppm ~ 1.2 ppm |
| OZONE (O3) Density in Air | Below 0.01 ppm |
| Power Consumption | 15W |
| Size | 210(H)*180(L)*115(D) mm |
| Temperature Range for Application | 5°C ~ 45°C (not exceed 60°C) |
| Weight | 4 kgs |
| Else | required water pressure above 1 kg/cm² |
